FRAME |
Size |
450, 500, 550mm |
Color |
Burn BLACK, Vintage RED |
Frame |
Full Cr-Mo Mid-size D.B. TIG Welding |
Fork |
Cr-Mo w/Investment-cast Crown |
Head set |
FSA INTELLASET 1-1/8”AHEAD w/5,10,10,15mm Spacers |
BB set |
SHIMANO SORA |
COCKPIT |
Handle Bar |
JD Shallow-Drop 380mm(450) / 400mm(500,550) Φ31.8 |
Handle Stem |
KALLOY AS-007N -17° Flip-Flop 70mm(450) / 80mm(500) / 90mm(550) |
Bar-tape/Grips |
Diamond-pattern w/RALEIGH Logos |
DRIVE TRAIN |
Shifter |
SHIMANO SORA 9×2speed Dual-Control Levers W/Cable adjusters for Downtube-levers |
Rear Derailleur |
SHIMANO SORA SS |
Front Derailleur |
SHIMANO SORA 28.6mm |
Chainwheel |
SHIMANO SORA 50-34T w/Gear-guard×165mm(450) / 170mm(500,550) |
Gear |
SHIMANO CS-HG200-9 11-32T 9speed |
Chain |
SHIMANO CN-HG53 |
Pedals |
WELLGO LU-962 ALLOY COMPACT |
BRAKE |
Brakes |
SHIMANO SORA |
Levers |
SHIMANO SORA Dual-Control Levers TEKTRO RL721 Top-mount Levers |
WHEELS |
Hubs |
SHIMANO SORA 32H 100×130 |
Spokes |
14G Stainless |
Rims |
SHINING RIMS A-220 700C Silver / CNC 32H |
Tires |
CONTINENTAL 700×25C ULTRA SPORTS F/V |
SEAT |
Saddle |
VELO Racing Cr-Mo Rail RALEIGH-spec |
Seat Pillar |
KALLOY SP-373 27.2×300 |
|
Weight |
10.8kg |
